SPECIAL TOOLS

L4566TN

L4566TN Transmission sensor module remover kit has all the disconnection tools needed to work with the VAG transmission sensor module.

Assembly group: maintenance 7-speed dual clutch gearbox 0B5 (S tronic).

Application: Audi A4 2008 >, Audi A5 Cabriolet 2009 >, Audi Q5 2008 >

Audi A5 2008 >, Audi A7 2011 >, etc.

VAG numbers T40217, T40228.

L4083TN

The transmission sensor module remover kit has all the disconnection tools needed to work  with the 0B5 transmission sensor module.

Compatible with Audi A4 2008 >, A5 Cabriolet 2009 >, Q5 2008 >, Audi A5 2008 >, A7 2011 >, etc. OEM: Equivalent T40217 Trans Side Shaft Counterhold Tool and T40228 Sensor Module Tool

L4094TN

Socket set is specially designed for using in suspension struts, brake, calipers, transmission screws, oil screws and wheel bearing areas etc

VW and Audi group.

• Contents:
• 1/2″ Dr. x 78 mm: M12, M14, M16, M18 = 4 pcs.
• 14 mm hex Dr. x M14 30 mm (Length) = 1 pc.
• 17 mm hex Dr. x M16H 32 mm (Length) = 1 pc.
• Total: 6 pieces.

L4152TN

Diesel injector remover kit designed to remove the seized diesel injector from VAG TDI engine  Application: Compatible with 1.6L TDi CR diesel and 2.0L TDi;  Compatible with Audi A3 (2009/2013); Compatible with Volkswagen Golf  (2009); Compatible with Seat Ibiza (2008); Compatible with Toledo  (2013); Compatible with Altea, Leon, Altea XL, Altea Freetrack (all  2009);

OEM ref numbers T10402 and T10415

L1305TN

Set of tools for assembly and disassembly of the upper supporting joints.

Suitable for VW T4 front axle. T4 2000 CC, T4 2500 CC

Designed for the removal and installation of suspension ball joints

on the vehicles and the assembly doesn't need to remove the sub-frame.

Package includes:

Hardened spindle with 24mm hex drive.

3 different pressure plates.

2 reducing forks with locking functions.

L4862TN

VW water pump removal tool kit is specially designed for removing the water pump.

Loosen the exhaust pipe and starter catalytic converter from the Turbo Charger and Gearbox for engine BAC and BLK.

Remove the exhaust gas re-circulation cooler and particulate filter for engine BDP and BPE. Appl: VW T5 and Touareg 2.5D.

Engine codes: BAC, BLK, BPD, BPE

L4893TN

Fuel injector  remover kit makes fuel injector pulling a painless process on all 2.0L  TSI/FSI/TSFI engines; This kit is great time saver.

The slide hammer puller set and adapters allows you to  reseal and reinstall fuel injectors; Injector puller set includes special attachments to aid with re-installation

This set includes an installation tool, mini slide hammer, 2-jaw puller attachment, standard  puller attachment, an assembly cone, and 3 calibration sleeves.

L6621TN

VAG injector combination tool set is specially designed for removing  and installing of the high pressure injectors and combustion chamber  seal in FSI fuel injector.

Application: 1.4, 1.6, 1.8, 2.0, 2.7 V6, 3.0 V6, 3.2 V6, 3.6 V6, 4.2 V8 FSI engines.

VAG Ref number: T10133C

L6702S

VAG camshaft adjusting socket set

For removal & installation of 4/3-way  central valve for camshaft adjustment. Services 1.8L & 2.0L (4v)  generation 1, 2 & 3 TFSI engines.

5 sizes with unique 2-pin  positions.

All with 3/8" square drive.

Ref #T10352, #T10352/1A, #T10352/2, #T10352/3 and #T10352/4

L6880TN

VAG transmission gear remover is specially designed for pulling off 6th speed gear wheel including synchro-hub on 6-speed manual gearbox 02S,

5-speed manual gearbox 0A4

Ref number: T10309A.

L6970TN

Camshaft Turning Adapter/Socket Set (3 Pc)

Tools used for rotating and hold the intake camshaft when adjusting the timing chain.

Application: 4-cylinder direct injection 1.8/ 2.0 TFSI engine (EA888).

Ref numbers: T40266, T10567 and camshaft OE # 06J109088 found on VAG EA888 MK2 1.8T/ 2.0T.

L4745TN

VW, Audi crankshaft pulley remover

specially designed to remove the front pulley from the crankshaft.

Application: VW, Audi 4 and 5-cylinder engines.

L4509TN

VAG Oil Seal Guide tool set is a special tool for precise installing of the o-rings and positioning the pump or nozzle unit.

Set to prevent damages to the cylinder head, pump, and nozzle unit.

Application:  VW Phaeton and Touareg from 2003; T5 from 2004 (5 and 10-cylinder  diesel engines); Touareg from 2004; Audi A3 from 2004 (4-cylinder /  4-valve diesel engine).

L4576TN

VAG timing tool set is specially designed to lock the camshaft when adjusting timing.

Application: Audi A8 2010 >, Audi A6 2011 >, 8-cylinder 4.0L, 4V TFSI engine, mechanics.

VAG Ref number: T40264.

L6692TN

VAG ENGINE TIMING TOOL SET 2.5 TFSI

Tool set is specially designed with the essential  components to lock the engine into TDC position so the timing chain can  be replaced or the cam timing checked.

Application: Audi RS, Q3, TT 2.5 TFSI engine, CZGA, CZGB, CEPA, CEPB, CTSA.

Ref numbers: T40079, T40070, T40069, T03003, T03006

L6626TN

VAG Vibration Damper Assembly Tool

Specially designed to fix the timing chain drive sprockets while installing and removing the vibration damper on VAG 1.8/2.0 TFSi/TSi EA888 engine.

OEM kit Reference number: T10531

Contents:

T10531/1 Vibration damper holding tool

T10531/3 Crankshaft sprocket holding tool adapter

T10531/2 Crankshaft sprocket holding tool

T10531/4 Crankshaft sprocket holding tool nut

L6639TN

VAG camshaft pulley Holder tool Set

Designed to hold camshaft, crankshaft, oil pump and water pump pulleys and sprockets while loosening and tightening the fixing bolts.

Complete set of adapters: 4.8mm, 6mm; square 15 x 6mm, square 15 x 12mm; 13 x 17mm and 16 x 20mm cups; Spline M10 and M12.

Applicable: VAG 3-cyl. 4-cyl. (1.0L, 1.2L, 1.4L EA211 turbocharger),

2.0L engines FSi, TSi, TFSi.

Equivalent to OEM T10172A (T10172) and T10554.
